Decoding of codes of malfunctions


B - body;

C - chassis (suspension);

P - engine (ECM), gearbox;

U - data exchange bus.




1, 2 - fuel system;

3 - ignition system;

4 - reducing toxicity

exhaust gases;

5 - idle;

6 - ECU or its circuits;

7, 8 - transmission (automatic transmission).


Fault Code

How do I clear the error?


If the instrument panel shows a check, the easiest way to throw off the error is to disconnect the battery for a few minutes. But it must be borne in mind that in this way only the code itself can be removed from the memory of the on-board computer or the instrument panel, however, it will not be possible to erase the malfunction directly. Therefore, the combinations must be removed after repair.


To reset the memory on Volvo cars of 92, 93, 94 and 95 with the old testing system, the following actions are performed:


In the car, the ignition system is activated by turning the key in the lock.

The key is pressed to start the diagnostic process, which must be held down for 6-8 seconds.

Wait until the LED indicator on the dashboard on-board computer lights up (it should appear after about 3 seconds).

Then the key for activating the testing process is again clamped for 6-8 seconds, which will turn off the diode element.

A check is made for the presence of fault codes in the memory of the control unit. If the actions to clear the memory are performed correctly, the LED will send code 111.

If you want to remove the indicator of the need for a service interval on Volvo XC60, XC70 and XC90 cars, the following actions are performed:


The key is inserted into the lock and scrolled into "I" mode.

The button on the odometer is pressed and held for a few seconds, during which the daily mileage should be reset.

Within two seconds after resetting the values, the user must move the key in the lock to position "II". The odometer button while performing these actions must be held until the indicator in the form of an orange triangle appears on the dashboard display.

Then the mileage reset button is released and the ignition system is turned off. After that, the indication of the service interval must be deleted from the memory of the control unit.

For Cummins cars, C60, C80, XC70 & other Volvo models, the procedure for deleting random trouble codes is as follows:


The driver gets behind the wheel of the vehicle and closes the door behind him. When carrying out this procedure, all door locks of the car must be locked.

The key is inserted into the lock and turns first into the "I" mode, and then comes back. It is not necessary to remove the device from the switch.

The reset button for the daily mileage on the dashboard is pressed. At the same time, the user must turn the key in the lock to the “I” position.

Then, holding the key down, the user must wait 10-15 seconds. The indicator of unfastened safety belts or airbags should blink on the display. The dashboard will beep. The pulse duration should be about 1 s.

Then, on the dashboard of the machine, on the left side of the display, fault codes will appear. All errors are separated by commas. This completes the procedure for resetting errors for trucks and light vehicles.
